Why a Heim Joint with a 7/8"-14 TPI Thread Cannot Replace a Tie Rod End with a 7/8"-18 TPI Thread When working on vehicle steering or suspension systems, it’s important to use the correct components to ensure both performance and safety. One common issue mechanics or DIY enthusiasts encounter is determining whether certain components are interchangeable. A frequent question arises regarding the possibility of replacing a tie rod end (TRE)...

Here is a sneak peek at our new 1.5" Heim Joint. It is much bigger than the 1.25" heim that is currently the industry standard for most trucks and jeeps. This 1.5" joint is much stronger with a longer shaft and a bigger 1.25" bore.  Check out the video and pictures to see it compared to the 1.25" heim. https://youtube.com/shorts/b_UsBKxvn_E?feature=share

 A Heim joint, also known as a spherical rod end, is a pivot joint that allows for a limited amount of misalignment between the two rods or linkages that it connects. It is made up of a spherical bearing that is captured in a housing.   The bearing is made up of a ball and socket, and the housing has two threaded holes that the rods or linkages can be...

Heim joints are better than bushings in a few key ways: Precision: Heim joints are more precise than bushings, which means that they can transmit more force and torque without binding or flexing. This is important for applications where precise control is required, such as racing or off-road driving. Durability: Heim joints are more durable than bushings, and they can withstand more abuse without breaking or wearing out. This makes...

Polyurethane (poly) bushings are commonly used to mount engines in vehicles for several reasons:1. Vibration Isolation: Engines produce significant vibrations during operation. Poly bushings have excellent vibration-dampening properties, which help isolate the engine's vibrations from the vehicle's chassis. This reduces the transfer of engine vibrations to the rest of the vehicle, resulting in a smoother and more comfortable ride.2. Improved Performance: Poly bushings offer superior stiffness compared to rubber bushings....

Heim joints, also known as rod ends or spherical rod ends, are essential components in various mechanical systems. They offer a versatile means of connecting rods or linkages, allowing for angular motion while transmitting force. Understanding how Heim joints are made provides valuable insight into the intricacies of their manufacturing process and sheds light on the high precision and engineering involved. In this article, we delve into the fascinating world...
